Main Features: • Psychoacoustic Composite Embedder allows up to 140% audio peaks in stereo at 100% total modulation. • Full IP remote control with remote audio streaming • Optional RDS encoder • Selectable SSB (Single Sideband) stereo encoder • Analysis tools for internal or external composite signals
Specifications: • Frequency Response: +/- .5 dB 20 Hz to 15 kHz • Signal-Noise Ratio: Greater than -80 dBu de-emphasized, 20 Hz to 15 kHz • Stereo Separation: 65dB minimum, 20 Hz to 15 kHz, 70 dB typical • Stereo Baseband Output: Adjustable from -2 dBu to +22 dBu (0.1 dB increments) into 600-Ohms, 20-Ohm output impedance • Analog Inputs: Two balanced, EMI filtered XLR connectors • Digital Inputs: AES/EBU In & External Sync • Composite I/O: Four 75-Ohm BNC female, two inputs, two outputs • Remote Control: RJ45 supporting 100 Base-T Ethernet connections • Power Requirements: 100-264 VAC, 47-63 Hz autosensing • Power Connector: IEC male, detachable 3-wire power cord supplied • Environmental: Operating: 0 to 50 degrees C Non-Operating: -20 to 70 degrees C
